DOUBLE BLOCK - UPRIGHT
Art. 7804250
The Barton block with two sheaves is built so that with a vertical eye, oriented for a pull coming from above or below rather than from the side; the mechanical advantage is greater than a single block, useful for building a purchase when one sheave isn't enough.
Body in corrosion-resistant marine materials, rated for a 750 kg working load and a 1500 kg breaking load: figures to respect as the equipment's safety margin, not to approach as normal use.
Technical specifications:
- Maximum line diameter 12 mm
- Maximum working load 750 kg
- Breaking load 1500 kg
- Sheave dimensions 54 x 17 mm
- Length 92 mm
Body in corrosion-resistant marine materials, rated for a 750 kg working load and a 1500 kg breaking load: figures to respect as the equipment's safety margin, not to approach as normal use.
Technical specifications:
- Maximum line diameter 12 mm
- Maximum working load 750 kg
- Breaking load 1500 kg
- Sheave dimensions 54 x 17 mm
- Length 92 mm
Available
Availability over 7d
| Product | Ø Wire | Dimensions | Working load | Breaking Load | Model | TYPE | Price list €(vat incl.) | Unit | Avail. |
|---|---|---|---|---|---|---|---|---|---|
7804250
|
MAX 12 MM | PULLEY 57m - BASE 60 x 67mm - Dim Max 76x90H x76mm | 750 KG | 1500 KG | DOUBLE | UPRIGHT | €110.02 | N | 1 |
