SINGLE FIXED EYE CLEVIS PIN WITH BECKET
Art. 7805091
The Barton block with a single sheave is built so that the removable pin lets the block be threaded onto an eye or shackle already in place, without opening a snap shackle or dismantling anything else; the fixed eye doesn't rotate, the right choice when the pull direction never changes. Fitted with a becket at the base, useful for securing the line's end or for building a purchase with a greater mechanical ratio.
Body in corrosion-resistant marine materials, rated for a 750 kg working load and a 1500 kg breaking load: figures to respect as the equipment's safety margin, not to approach as normal use.
Technical specifications:
- Maximum line diameter 12 mm
- Maximum working load 750 kg
- Breaking load 1500 kg
- Sheave dimensions 57 mm
- Length 137 mm
Body in corrosion-resistant marine materials, rated for a 750 kg working load and a 1500 kg breaking load: figures to respect as the equipment's safety margin, not to approach as normal use.
Technical specifications:
- Maximum line diameter 12 mm
- Maximum working load 750 kg
- Breaking load 1500 kg
- Sheave dimensions 57 mm
- Length 137 mm
Available
Availability over 7d
| Product | Ø Wire | Ø | Working load | Breaking Load | Model | TYPE | Price list €(vat incl.) | Unit | Avail. |
|---|---|---|---|---|---|---|---|---|---|
7805091
|
MAX 12 MM | PULLEY 54 MM X H 17 MM | 750 KG | 1500 KG | SINGLE | FIXED EYE CLEVIS PIN + BECKET | €58.18 | N | 1 |
