DP2 WINDLASS WITH DRUM
Art. 0307013
The Quick DP2 anchor windlass, verticale body, with drum, handles the anchor manoeuvre while matching the pull the boat actually needs: base, drum and gypsy cover in AISI 316 stainless steel, with a composite interior combining strength and low weight. The manual free-fall system lets the chain run out quickly without turning the motor, while the inspection hatch gives direct access to the gypsy for maintenance.
Sealed motor and anodized aluminium gearbox for long service life even in a salt-air environment. Rope and chain run on a single gypsy, with a built-in rope-tensioning device. Suited to boats from 7 a 12 metres.
Technical specifications:
- 700W power, 12V voltage
- 680 kg maximum instant pull
- Ø6mm chain, Ø12mm rope
- 22,6 m/min retrieval speed
- 16,3 kg weight
- AISI 316 stainless steel base, drum and gypsy cover
- Sealed motor, anodized aluminium gearbox
- Manual chain free-fall system
Sealed motor and anodized aluminium gearbox for long service life even in a salt-air environment. Rope and chain run on a single gypsy, with a built-in rope-tensioning device. Suited to boats from 7 a 12 metres.
Technical specifications:
- 700W power, 12V voltage
- 680 kg maximum instant pull
- Ø6mm chain, Ø12mm rope
- 22,6 m/min retrieval speed
- 16,3 kg weight
- AISI 316 stainless steel base, drum and gypsy cover
- Sealed motor, anodized aluminium gearbox
- Manual chain free-fall system
Available
Availability over 7d
| Product | Drum | Boat Length | Thickness | POWER | Instant pull | Ø | Speed | Weight | Price list €(vat incl.) | Unit | Avail. |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
0307018
|
YES | 8-13 MT | DECK 25/50 MM | 1000 WATT - 12 VOLT | MAX 930 KG | CHAIN 6 MM - ROPE 12 MM | RECOVERY 31,2 MT/MIN | 17,4 KG | €2,120.97 | N | 1 |
|
0307019
|
YES | 8-13 MT | DECK 25/50 MM | 1000 WATT - 12 VOLT | MAX 930 KG | CHAIN 8 MM - ROPE 12 MM | RECOVERY 31,2 MT/MIN | 17,4 KG | €2,120.97 | N |
4
18/11/2026
Alert The date is purely indicative |
|
0307013
|
YES | 7-12 MT | DECK 25/50 MM | 700 WATT - 12 VOT | MAX 680 KG | CHAIN 6 MM - ROPE 12 MM | RECOVERY 22,6 MT/MIN | 16,3 KG | €1,995.94 | N | 1 |
